Vape Coil Compatibility Guide: Which Coil Fits Your Device
Coils are not universal. A coil that physically fits is not always the right coil, and series names change between generations of the same device.
Match the series name first, then the resistance. Both are printed on the coil you already have — usually stamped on the metal body or the base, in the form GTX 0.6Ω or PnP-VM1 0.3Ω.
VOOPOO
The PnP series is the widest range we carry, and PnP coils fit across the Drag, Vinci and Argus lines.
| Coil | Resistance | Draw |
|---|---|---|
| PnP C1 | 1.2Ω | MTL |
| PnP R2 | 1.0Ω | MTL |
| PnP R1 / PnP TM2 | 0.8Ω | MTL |
| PnP M2 / PnP VM4 / PnP TM1 | 0.6Ω | Restricted DL |
| PnP M1 / PnP VM3 | 0.45Ω | Restricted DL |
| PnP VM1 | 0.3Ω | DL |
| PnP VM5 | 0.2Ω | DL |
| PnP VM6 | 0.15Ω | DL |
Also stocked: TPP coils (DM1, DM2), the Uforce U6 coil, and the PnP RBA deck for building your own.
SMOK
| Device | Coil | Resistances |
|---|---|---|
| Nord | Nord Coils (5-pack) | 0.6Ω DC · 0.6Ω Mesh · 0.8Ω Mesh MTL |
| RPM | RPM Coils (5-pack) | 0.4Ω · 0.6Ω · 0.8Ω · 1.0Ω · 1.2Ω — Mesh, Triple, Quartz, DC MTL, SC |
| RPM 2 | RPM 2 Coils | 0.16Ω Mesh · 0.6Ω DC |
| RPM 3 | RPM 3 Coils | 0.15Ω Mesh · 0.23Ω Mesh |
| Novo / LP1 | LP1 Coils | 0.8Ω DC MTL · 0.9Ω Mesh MTL · 1.2Ω Mesh |
| TFV16 tank | TFV16 Conical Mesh | 0.2Ω Kanthal |
| RPM 40 | RPM 40 RBA | 0.6Ω rebuildable deck |
RPM, RPM 2 and RPM 3 coils are not interchangeable. Check which generation your device is before ordering.
Vaporesso
| Series | Resistances | Fits |
|---|---|---|
| GTX | 0.2Ω · 0.3Ω · 0.6Ω Mesh | Target PM80 and Target 2 |
| GTi | 0.6Ω | GTi tanks, including the one on the Armour S kit |
| NRG GT Core (3-pack) | GT2 · GT4 · GT6 · GT8 · GT Mesh · GT cCell · GT cCell2 | NRG tanks |
UWELL Caliburn
| Device | Coil | Resistances |
|---|---|---|
| Caliburn G | Caliburn G Coils (4-pack) | 0.8Ω · 1.0Ω |
| Caliburn G2 | Caliburn G2 Coils (4-pack) | 1.2Ω |
G and G2 coils are different parts. The G2 takes the 1.2Ω only.
Other brands
| Device | Coil | Resistances |
|---|---|---|
| GeekVape G series | G Mesh Coil | 0.6Ω Mesh · 1.2Ω |
| Lost Vape Ultra Boost | Ultra Boost V2 | 1.0Ω MTL · M3 0.15Ω |
| Wismec R80 | R80 Coils (5-pack) | 0.3Ω · 0.8Ω — WV-M, WV01 |
| VEIIK Airo Pro | Airo Pro Coil | 1.2Ω BVC MTL · 0.6Ω Mesh DTL |
| ASVAPE Hita Mech | Hita Mech Coil | 0.5Ω Mesh · 1.0Ω Mesh · RBA |
What the resistance means
| Resistance | Draw | Pair with |
|---|---|---|
| 0.8Ω and above | Tighter mouth-to-lung, less vapour, longer battery life | 20mg+ salt nicotine, 50/50 |
| 0.6Ω and below | Open direct-to-lung, more vapour, heavier liquid use | Lower-strength freebase, higher VG |
Match the coil to the liquid as well as to the device. A 20mg salt liquid through a 0.3Ω coil delivers far more nicotine per puff than intended.
Refillable pods with the coil built in
Many pod kits have no separate coil. The coil is part of the pod: you fill it with your own e-liquid and replace the whole pod when the flavour fades. Match the device name exactly — pods from different generations of the same brand often do not fit.
| Device | Pod | Options |
|---|---|---|
| Aspire Pixo Kit | Pixo Pods | 0.4Ω · 0.6Ω · 1.2Ω |
| DOVPO Ayce, Ayce Pro 2 | Ayce Pods | 0.6Ω · 0.8Ω |
| GeekVape Aegis One | Aegis One Pods | 0.8Ω · 1.2Ω |
| Lost Vape Ursa Nano, Ursa Baby | Ursa Nano Cartridge | 0.8Ω · 1.0Ω |
| Orchid IQS | IQS Mesh Pod (2-pack) | 0.8Ω mesh, 3ml |
| OXVA XLIM series — XLIM Pro 2, XLIM SQ Pro, XLIM SQ Pro 2, XLIM Go 2, XLIM Pro 3 | XLIM Cartridge | 0.4Ω · 0.6Ω · 0.8Ω · 1.2Ω |
| OXVA NeXLIM series — NeXLIM Kit, NeXLIM Go | NeXLIM Cartridge | 0.8Ω · 1.2Ω |
| SMOK Mico | Mico Pod | 0.8Ω mesh · 1.4Ω ceramic |
| SMOK Novo | Novo Pods (3-pack) | 0.8Ω mesh · 1.0Ω mesh · 1.2Ω · 1.4Ω regular, quartz or ceramic · 1.5Ω |
| SMOK SLM | SLM Cartridge | 0.8ml |
| UWELL Caliburn A3 Kit | Caliburn A3 Pods | 2ml |
| Vaporesso Degree | Degree Pod | 0.6Ω mesh · 1.3Ω CCELL ceramic |
| Vaporesso XROS series — XROS Mini, XROS 3, XROS Nano, XROS 4, XROS 4 Nano, XROS 5 | XROS Pods (4-pack) | 0.8Ω mesh · 1.2Ω |
| VEIIK Moos | Moos Pods | Ceramic, 2ml |
| VOOPOO Argus Pod Kit, Argus P1 | Argus Pod Cartridge | 0.7Ω · 1.2Ω |
| VOOPOO Argus G3, G3 Mini, P3 | Argus Top Fill Cartridge V2 | 0.4Ω · 1.0Ω |
Empty pods
Some devices take a separate pod and coil. We stock empty pods for:
- SMOK Acro — 0.8Ω mesh or 0.6Ω MTL
- SMOK RPM80 and RGC — 5ml, three to a pack, no coil included
- SMOK Trinity Alpha — 2.8ml; it takes Nord coils
- UWELL Caliburn G2 — 2ml, no coil included
- UWELL Caliburn X
- Vaporesso Target PM80 — 4ml; it takes GTX coils
- Vaporesso Moti X Mini — 4ml
- Joyetech Exceed Grip — five cartridges, coil not included
Check the product title — some listings are the pod body only, with no coil included.
How long a coil lasts
One to three weeks of regular use is typical. Sweetened liquids — dessert, candy and most iced fruits — caramelise on the coil and can cut that to under a week. A burnt edge to the flavour, weak vapour or a gurgle are the usual signs it is finished.
Prime every new coil: fit it, fill the pod or tank, then wait five to ten minutes before the first puff. Firing a dry coil ruins it in one pull.
Still not sure?
Send us a photo of your device or the old coil on WhatsApp and we will tell you which one you need. Browse the full pods and coils range, or see delivery times — orders before 10:30pm go out the same day.
